P12 is a 10.1inch industrial tablet with android14 OS based on Qualcomm octa-core 2.0 GHz CPU,support swift, efficient user experiences,it is equipped with 10000mah large battery,camera,wifi,bluetooth, and features versatile functionalities such as barcode scanning, NFC, RFID,fingerprint, face recognition etc,which is an Ideal helper for retail, logistics, warehousing, asset,attendance,identity verification management,etc.
| PECIFICATIONS | ||||
| PHYSICAL CHARACTERISTICS | USER ENVIRONMENT | |||
| Dimension | 230mm(H)x146mm(W)x20mm(D)±2 mm | Operating Temp | -20℃ to 50℃ | |
| Weight | Net Weight :600g(including battery&wrist strap) | Storage Temp | -20℃ to 70℃ | |
| Display | Tough 8.0 in. TFT-LCD(800×1280)touch screen with backlight | Humidity | 5%RH to 95%RH(non-condensing) | |
| Backlight | LED backlight | Drop Specifications | 5ft./1.5 m drop to concreteacross the operating temperature range | |
| Expansions | 2 PSAM, 1 SIM, 1 TF， | Sealing | IP67, IEC compliance | |
| Battery | Rechargeable li-ion polymer, 3.8V,8000mAh | ESD | ±15kv air discharge, ±8kv direct discharge | |
| PERFORMANCE CHARACTERSTICS | FINGERPRINT READER(OPTIONAL) | |||
| CPUCPU | Cortex A73 2.0GHz octa-core | Sensor | TCS1 | |
| Operating System | Android 10.0 | Sensor type | Capacitive, area sensor | |
| Storage | 2GB RAM /16GB ROM or 4GB RAM/64GB ROM, MicroSD(max 256GB expansion) | Resolution | 508 DPI | |
| Camera | Rear 13 megapixel, front 5.0 megapixel | Performance | FRR<0.008%, FAR<0.005% | |
| Capacity | 1000 | |||
| DATA COMMUNICATION | BARCODE READER(OPTIONAL) | |||
| WWAN | 4G:TDD-LTE Band 38, 39, 40, 41; FDD-LTEBand 1, 2, 3, 4, 5,7,8,12, 17, 20; 3G:WCDMA (850/1900/2100MHz); 2G:GSM/GPRS/Edge (850/900/1800/1900MHz); | 2D Imager Scanner | Honeywell N6703/ Honeywell N6603 | |
| WLAN | 2.4GHz/5.0GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac | Symbologies | PDF417, MicroPDF417, Composite, RSS TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, U PostNet, US Planet, UK Postal, Australia Postal, Japan Postal, Dutch Postal. etc | |
| WPAN | Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.2 | |||
| GPS | GPS(embedded A-GPS), accuracy of 5 m | . | ||
| UHF RFID(OPTIONAL) | HF/NFC(OPTIONAL) | |||
| Frequency | 865~868MHz/920~925MHz/902-928MHz | Frequency | 13.56MHz | |
| Protocol | EPC C1 GEN2/ISO 18000-6C | Protocol | ISO 14443A&15693, NFC-IP1, NFC-IP2 | |
| Antenna Gain | Circular antenna(2dBi) | R/W Range | 3cm to 5cm | |
| R/W Range | 1.5-2m(depend on tags and environment) | |||
| LF RFID(OPTIONAL) | PSAM SECURITY(OPTIONAL) | |||
| Frequency | 125KHz/134.2KHz(FDX-B/HDX) | Protocol | ISO 7816 | |
| Protocol | ISO 11784&11785 | Baudrate | 9600, 19200, 38400,43000, 56000,57600, 115200 | |
| R/W Range | 2cm to 10cm | Slot | 2 slots(maximum) | |
